High Transparency
This LED display boasts an astonishing 80-90% transparency, merging seamlessly with its environment while providing high-quality visuals.
Flexible and Curvable
No Framework Required: The beauty of Transparent LED mesh lies in its simplicity. No need for additional structures or frames. It perfectly integrates with the existing architecture, offering limitless possibilities for architects and designers to bring their vision to life.
Lightweight
With a thickness of just 2mm, the Transparent LED Film is a testament to our commitment to sleek, modern design products. This ultra-thin film transforms any glass surface into a dynamic display without adding bulk.
High Transparency
This LED display boasts an astonishing 80-90% transparency, merging seamlessly with its environment while providing high-quality visuals.
Flexible & Curvable
No Framework Required: The beauty of Transparent LED mesh lies in its simplicity. No need for additional structures or frames. It perfectly integrates with the existing architecture, offering limitless possibilities for architects and designers to bring their vision to life.
Lightweight
With a thickness of just 2mm, the Transparent LED Film is a testament to our commitment to sleek, modern design products. This ultra-thin film transforms any glass surface into a dynamic display without adding bulk.
Starlink Technical-Parameters
| Specification | P2.5 / P2.5 | P3.91 / P3.91 | P6.25 / P6.25 |
|---|---|---|---|
| Visual Transparency Rate | 70% | 80% | 90% |
| Physical Transparency Rate | 35% | 50% | 65% |
| Pixel Density (dot / m²) | 160,000 | 65,536 | 25,600 |
| Module Size with pixels (mm) (W*H) | 125x1000 | 250x1000 / 250x1175 | 250x1175 / 250x1475 |
| Module Resolution (dot) (W*H) | 50x400 | 64x256 / 64x300 | 40x188 / 40x236 |
| Maximum Screen Height (m) | 2 | 2.4 | 3 |
| Brightness (cd / m²) | 1,200 | 3,000 | 4,000 |
| Weight (kg / m²) | 6.5 | 6 | 5 |
| Encapsulation Type | LED & IC packed in one | LED & IC packed in one | LED & IC packed in one |
| Scanning Mode | Static Driving (Single Pixel Single Control) | Static Driving (Single Pixel Single Control) | Static Driving (Single Pixel Single Control) |
| Lifespan | ≥ 100,000.00 hours | ≥ 100,000.00 hours | ≥ 100,000.00 hours |
| Gray Scale | 65,536 (16bit) | 65,536 (16bit) | 65,536 (16bit) |
| Maximum Power Consumption (w / m²) | 1000 | 1000 | 1000 |
| Average Power Consumption (w / m²) | 300 | 300 | 300 |
| Control System | Novastar | Novastar | Novastar |
| Control Way | Synchronous / Asynchronous | Synchronous / Asynchronous | Synchronous / Asynchronous |
| Input Voltage | AC100~240V 50/60 Hz | AC100~240V 50/60 Hz | AC100~240V 50/60 Hz |
| Module Working Current | DC 4.2V ± 0.2V | DC 4.2V ± 0.2V | DC 4.2V ± 0.2V |
| Operation Temperature | 0~50°C | 0~50°C | 0~50°C |
| Operation Humidity | 20%RH ~ 85%RH | 20%RH ~ 85%RH | 20%RH ~ 85%RH |
| Storage Temperature | -20~60°C | -20~60°C | -20~60°C |
| Storage Humidity | 10%RH ~ 85%RH | 10%RH ~ 85%RH | 10%RH ~ 85%RH |
| Certificate | CE, EMC, LVD, CCC | CE, EMC, LVD, CCC | CE, EMC, LVD, CCC |
